Seni Jaya Logo
Visitor

SORAA/SSL-EY632-TIO LED SOLAR STREET LIGHT

05-Jul-2022
SORAA/SSL-EY632-TIO LED SOLAR STREET LIGHT
Product Viewed 163
Product Specifications
Wattage Range 30W, 60W, 70W, 80W, 90W, 100W, 120W & 150W
Solar Panel 30W: 80Wp 60W: 130Wp 70W: 150Wp 80W: 160Wp 90W: 180Wp 100W: 200Wp 120W: 240Wp 150W: 300Wp
Battery Capacity 30W: 614.4Wh 60W: 1152Wh 70W: 1382.4Wh 80W: 1536Wh 90W: 1843.2Wh 100W: 1997Wh 120W: 2304Wh 150W: 2918Wh
Solar System Voltage (V) 30W: 12V 60W: 12V 70W: 24V 80W: 24V 90W: 24V 100W: 24V 120W: 24V 150W: 24V
Days of Autonomy (Min Days) Min 2 Days autonomy 12h lighting, overcast & rainy days.
Product Features -Powerful and energy saving LED Lighting -Solar panels with high-efficiency monocrystalline solar cells -Robust and durable fixture build for perfection -Trusted and high-power LED lumen output -Long lasting, maintenance-free, high capacity batteries -Sufficient light output avoid disruption by moving objects -Smart Solar (Optional)
Applications Rural & Remote Area Coastal Area & Jetties Security & Area Lighting Residential & Industrial Area Main Road & Small Road

  TECHNICAL DATA

  MODEL EY632-30W EY632-60W EY632-70W EY632-80W EY632-90W EY632-100W EY632-120W EY632-150W
  Wattage (W) 30W 60W 70W 80W 90W 100W 120W 150W
  Lumen Output (lm) ± 5% 5,400 10,800 12,600 14,400 16,200 18,000 21,600 27,000
  Lumen Per Watt ± 5% 180 180 180 180 180 180 180 180
  Solar Panel (Wp) 80Wp 135Wp 150Wp 160Wp 180Wp 200Wp 240Wp 300Wp
  Solar Charging Time (Hrs) 2.85h 3.5h 3.5h 3.8h 3.8h 3.8h 3.8h 3.8h
  Battery Capacity (Wh) 614.4Wh 1152Wh 1382.4Wh 1536Wh 1843.2Wh 1997Wh 2304Wh 2918Wh
  Battery Voltage (V) 12.8V 12.8V 25.6V 25.6V 25.6V 25.6V 25.6V 25.6V
  Battery Capacity (Ah) 48Ah 90Ah 54Ah 60Ah 72Ah 78Ah 90Ah 114Ah
  Daily ConsumpTion (Wh) 228Wh 456Wh 532Wh 608Wh 684Wh 760Wh 912Wh 1140Wh
  Solar System Voltage (V) 12V 12V 24V 24V 24V 24V 24V 24V
  Days of Autonomy (Min Days) > min 2 days > min 2 days > min 2 days > min 2 days > min 2 days > min 2 days > min 2 days > min 2 days
  Fixture Dimension (mm)
(L) x (W) x (H)
1319 x 365 x 60 1529 x 485 x 60 1404 x 600 x 60 1539 x 605 x 60 1409 x 700 x 60 1659 x 605 x 60 1845 x 700 x 60 1849 x 845 x 60
  Panel Size (mm)
(L) x (W)
1310 x 340 1520 x 460 1395 x 575 1530 x 580 1400 x 675 1650 x 580 1836 x 675 1840x 820
  Fixture Carton Size
(L) x (W) x (H)
1362 x 408 x 123 1572 x 527 x 123 1447 x643 x 123 1582 x 648 x 123 1452 x 743x 123 1702 x 648 x 123 1888 x 743 x 123 1892 x 888 x 123
  Adapter Carton Size
(L) x (W) x (H)
455 x 250 x 250 455 x 250 x 250 455 x 250 x 250 455 x 250 x 250 400 x 340 x 275 450 x 340 x 275 450 x 340 x 275 450 x 330 x 300
  Net Weight (kg)
(Fixture + Adaptor)
18kg
14.6kg (Fixture)
 3.40kg (Bracket)
29kg
25.60kg (Fixture)
3.40kg (Bracket)
32kg
28.6kg (Fixture)
3.40kg (Bracket)
34kg
30.6kg (Fixture)
3.4kg (Bracket)
37kg
32.0kg (Fixture)
5.0kg (Bracket)
41kg
36.1kg (Fixture)
5.4kg (Bracket)
50kg
45.1kg (Fixture)
5.4kg (Bracket)
59kg
53.3kg (Fixture)
5.7kg (Bracket)

  Gross Weight (kg)
(Fixture + Adaptor)
19.5kg
15.6kg (Fixture)
3.9kg (Bracket)
30.5kg
26.6kg (Fixture)
3.9kg (Bracket)
34.05kg
30.1kg (Fixture)
3.95kg (Bracket)
36kg
32.1kg (Fixture)
3.9kg (Bracket)
39.5kg
33.5kg (Fixture)
6.0kg (Bracket)
44.5kg
38.1kg (Fixture)
6.4kg (Bracket)
54kg
47.6kg (Fixture)
6.4kg (Bracket)
63kg
56.3kg (Fixture)
6.7kg (Bracket)

  CBM (m³) 0.068 0.102 0.114 0.126 0.132 0.135 0.172 0.206
  Note 1 : The above specified lumen and system efficiency based on standard CCT: 3000K~3500K, Ra>70
  Note 2: All model fullfil JKR L-S20 requirement. No motion sensor required, with > 2 autonomy days (overcast / rainy days)
  Note 3: Glass frame version (EMAL) available upon request. lm/W will be reduced.


  POST TOP MOUNTING DIAMETER & POLE HEIGHT

  MODEL 30W 60W 70W 80W 90W 100W 120W 150W
  Post Top, OD
Pole Diameter (Ø mm)
70~78 70~78 70~78 70~78 90~102 90~102 90~102 90~102
  Recommended
Pole Height (m)
5 to 6 7 to 8 7 to 8 7 to 8 9 to 10 10 to 12 10 to 12 12
  Pole Insert Depth,
d (mm)
d = 250mm


  PHOTOMETRY
